Apart from providing best in class off-road ability, Bell Trucks provide on board weighing and remote production monitoring to promote the best possible productivity.
Longer life > Higher residual values
6×6 Articulated Dump Trucks
B40E ADT S5
Maximum net power: 380 kW (510 hp)
Rated payload: 39 000 kg (85 980 lb)
Operating weight: 71 455 kg (157 531 lb)
Overview
Technical Data
- Download PIN3.6 English brochure
- Download PIN3.6 US brochure
- Download PIN3.6 German brochure
- Download PIN3.6 French brochure
- Download PIN3.6 Spanish brochure
| Engine | Mercedes Benz OM471LA (MTU 6R 1300) |
| Maximum Net Power | 380 kW (510 hp) |
| Certification | EU Stage V |
| Transmissions | Allison 4700 ORS |
| Retardation | Wet Brakes |
| Rated Payload | 39 000 kg (85 980 lb) |
| Body Capacity SAE 2:1 | 24 m³ (31 yd³) |
| Unladen Weight | 32 455 kg (71 551 lb) |
| Laden Weight | 71 455 kg (157 531 lb) |
| Standard Tyre Size | 29.5 R25 |
| Option Tyre Size | 875/65 R29 |
| Onboard Weighing | Standard |
| Fleetm@tic® Telematics | Standard |
| i-Tip | Standard |
| Automatic Turbo Spindown | Standard |
| Tip Safe | Standard |
| Neutral Park Brake | Standard |
| Front Comfort Ride | Standard |
