Drum Diameter: 2 100 mm – 1 600 mm
Gross Power: 129 kW @ 2 200 rpm
Operating Weight: 18 530 kg
Our latest generation of outstanding single-drum soil compactors has been carefully developed with intensive market research and leads its class in terms of quality, reliability, comfort and – most importantly – productivity. Discover how this outstanding range will make smooth work of even the toughest challenges.
Longer life > Higher residual values
Engine | Cummins B 5.9 - 150C |
Gross Power | 129 kW @ 2 200 rpm |
Emission | Tier 2 |
Drive | Hydrostatic Direct Drive |
Travel Speed | 11.8 km/h |
Tyres | 23.1 - 26/8 PR AWT |
Frequency | 29/35 Hz |
Amplitude | 2.0/0.75 mm |
Centrifugal Force | 370 kN/205 kN |
Gradebility (With Vibration) | 24 Degrees (%) |
Drum Width/Diameter | 2 100/1 600 mm |
Cabin | Enclosed, Air Conditioner with ROPS/FOPS |
Telematics | None |
Operating Weight | 18 530 kg |
Length/Height/Width | 5 996/2 985/2 270 mm |
Standard Warranty | 12 months, unlimited hours |
Standard Fitted Options | Compatronic compaction meter, |
road light kit, SASS (switchable anti slip system), | |
maintenance-free heavy-duty articulated center joint and power steering, | |
heavy-duty no-spin axle, avc (automatic vibration control), | |
hydraulically lifted hood centralized service station for hydraulics, | |
towing pump, reverse alarm | |
Additional Options | Pad foot shell kit |
