Maximum Net Power: 205 kW (275 hp)
Rated Payload: 24 000 kg (52 911 lb)
Gross Torque: 1 150 Nm (848 lbft)
Apart from providing best in class off-road ability, Bell Trucks provide
on board weighing and remote production monitoring to promote the best
possible productivity.
Longer life > Higher residual values
Engine | Mercedes Benz OM936LA (6R 1000 C31) |
Maximum Net Power | 210 kW (282 hp) |
Certification | EU Stage V / EPA Non-road Tier 4 Final emissions regulations |
Transmissions | Allison 3500PR ORS |
Retardation | Transmission |
Rated Payload | 24 000 kg (52 911 lb) |
Body Capacity SAE 2:1 | 15 m³ (19,5 yd³) |
Unladen Weight | 17 940 kg (39 551 lb) |
Laden Weight | 41 940 kg (92 462 lb) |
Standard Tyre Size | 20.5R25 |
Onboard Weighing | Standard |
Fleetm@tic® Telematics | Standard |
i-Tip | Standard |
Automatic Turbo Spindown | Standard |
Tip Safe | Standard |
Neutral Park Brake | Standard |
Front Comfort Ride | Standard |
