Maximum Net Power: 320 kW (429 hp)
Rated Payload: 33 500 kg (73 855 lbs)
Operating Weight: 32 363 / 65 862 kg
Apart from providing best in class off-road ability, Bell Trucks provide
on board weighing and remote production monitoring to promote the best
possible productivity.
Longer life > Higher residual values
Engine | Mercedes Benz OM471LA (MTU 6R 1300) |
Maximum Net Power | 320 kW (429 hp) |
Certification | EU Stage V / EPA Tier 4 Final emissions regulations |
Transmissions | Allison 4700 ORS |
Retardation | Wet Brakes |
Rated Payload | 33 500 kg (73 855 lb) |
Body Capacity SAE 2:1 | 20,5 m³ (27 yd³) |
Unladen Weight | 32 363 kg (71 348 lb) |
Laden Weight | 65 862 kg (145 201 lb) |
Standard Tyre Size | 26.5R25 |
Onboard Weighing | Standard |
Fleetm@tic® Telematics | Standard |
i-Tip | Standard |
Automatic Turbo Spindown | Standard |
Tip Safe | Standard |
Neutral Park Brake | Standard |
Front Comfort Ride | Standard |
